Niaj hnub nimno sheet hlau ua kev lag luam

Sheet hlau ua: niaj hnub ntawv hlau ua kev lag luam

Sheet hlau ua, raws li lub npe qhia, yog kev ua haujlwm txias txias rau cov ntawv hlau (feem ntau hauv qab 6 millimeters). Nws ua cov ntaub ntawv tiaj tus hlau rau hauv ntau yam peb- qhov sib txawv ntawm cov khoom siv los ntawm cov txheej txheem xws li txiav, khoov, stamping, thiab vuam. Los ntawm sab hauv ntawm cov xov tooj ntawm tes mus rau cov kab hlau rhuav phab ntsa ntawm cov skyscrapers, los ntawm cov khoom siv hauv tsev mus rau cov khoom siv hauv lub dav hlau, cov ntawv hlau yog qhov dav dav thiab yog ib qho ntawm feem ntau siv thiab tsim cov thev naus laus zis hauv kev lag luam niaj hnub no.



1, Core Process Flow: Txoj Kev Taug Kev los ntawm Kos duab rau cov khoom tiav

Cov txheej txheem hlau ua tau zoo yog cov saw hlau ntawm kev sib tshuam technologies:

Tsim thiab Engineering (Key Starting Point):

Kev kos duab hloov dua siab tshiab: nthuav tawm tus qauv 3D rau hauv 2D tiaj tus nthuav dav, suav nrog kev siv cov khoom siv thiab khoov nyiaj.

DFM (Design for Manufacturability) tsom xam: Cov engineers zoo heev yuav txiav txim siab txog kev siv tshuab xws li qhov tsawg kawg nkaus khoov vojvoog, qhov ntug qhov deb, cov cuab yeej cuam tshuam, thiab lwm yam, thiab ua kom zoo dua tus qauv tsim kom txo cov nqi thiab txhim kho cov txiaj ntsig.

Txiav (muab contour):

Laser txiav: Cov thev naus laus zis tseem ceeb tam sim no siv siab - lub zog laser beams rau tsis yog - kev sib cuag txiav, nrog siab precision thiab zoo saj zawg zog, haum rau complex graphics thiab me me mus rau nruab nrab batch.

CNC xuas nrig ntaus tshuab: siv cov pwm rau xuas nrig ntaus thiab txiav, haum rau qhov chaw nrog ntau tus qauv qhov thiab louvers, nrog rau kev ua haujlwm siab rau ntau qhov ntau.

Plasma txiav: haum rau cov pa roj carbon monoxide tuab, nrog ceev ceev, tab sis kuj tsis zoo cua sov cuam tshuam cheeb tsam thiab raug piv rau laser txiav.

Dej dav hlau txiav: siv ultra- dej siab ntws (sib xyaw abrasive) rau kev txiav, tsis muaj thermal deformation, tuaj yeem txiav txhua yam khoom, tab sis qeeb qeeb.

Forming (muab puab):

Khoov: cov txheej txheem tseem ceeb. Los ntawm kev siv lub tshuab CNC dabtsi yog khoov nrog cov pwm sab saud thiab qis, cov ntawv hlau tuaj yeem khoov rau hauv lub kaum sab xis uas xav tau los ntawm kev tswj xyuas cov hlab ntsha thiab lub siab. Qhov tseeb tuaj yeem ncav cuag ± 0.1 degrees.

Stamping / stretching: Siv lub siab ntawm cov pwm thiab cov tshuab xuas nrig ntaus kom ua rau cov yas deformation ntawm cov ntawv hlau, tsim cov concave convex, nyem, txhawb cov tav los yog cov plhaub sib sib zog nqus (xws li stainless hlau dab dej).

Kev sib txuas thiab kev sib dhos (endowing functionality):

Vuam: Feem ntau siv cov kev sib txuas mus tas li muaj xws li argon arc vuam (TIG / MIG, siv rau cov hlau tsis muaj steel thiab txhuas), qhov chaw vuam (siv rau nyias phaj sib tshooj), thiab laser vuam (siab-precision, qis deformation).

Fastener kev twb kev txuas: Tshem tau los ua ke yog tiav los ntawm riveting, rub riveting, los yog threaded kev twb kev txuas (xws li riveting ceev thiab screws).

Adhesive: Siv tshwj xeeb hlau nplaum, haum rau cov ntaub ntawv sib txawv lossis cov xwm txheej uas zam deformation.

Kev kho deg (muab zoo li thiab tiv thaiv):

Kev kho mob ua ntej: degreasing, xeb tshem tawm, phosphating, passivation, muab cov substrate zoo rau cov txheej tom ntej.

Txheej: hmoov txheej (ib puag ncig tus phooj ywg, hnav- tiv taus, muaj xim sib txawv), electrophoresis (kev tiv thaiv ib puag ncig, zoo corrosion kuj), electroplating (galvanized, chrome plated, npib tsib xee plated, muab kev tiv thaiv-corrosion lossis hniav zoo nkauj).

Conversion zaj duab xis: Anodizing (tsuas yog siv rau txhuas cov ntaub ntawv los txhim kho hardness, corrosion kuj, thiab xim muaj peev xwm).


2, Kev xaiv cov khoom siv: sib npaug ntawm kev ua haujlwm thiab tus nqi

Xaiv cov ntaub ntawv zoo yog ib nrab ntawm kev sib ntaus sib tua rau kev tsim kom tiav:

Txias dov steel phaj (SPCC): feem ntau siv, qis- nqi, muaj zog, yooj yim rau kev ua, thiab tuaj yeem kho nrog ntau yam kev kho deg.

Galvanized sheet (SECC/SGCC): los nrog cov txheej txheem xeb thiab feem ntau yog siv rau hauv chassis thiab cov txee, tab sis cov vuam qhov yuav tsum tau kho tshwj xeeb.

Stainless hlau (SUS304/316): corrosion-resistant, aesthetically pleasing, tab sis nrog pom tseeb ua hauj lwm hardening, yuav tsum tau siab rau cov cuab yeej txiav thiab cov txheej txheem.

Aluminium thiab aluminium alloys (xws li 5052-H32, 6061-T6): lub teeb yuag, zoo hluav taws xob thiab thermal conductivity, corrosion kuj, yooj yim rau khoov tab sis kuj mos, tus nqi siab.

Tooj / tooj dag: feem ntau yog siv los ua hluav taws xob, cua sov, lossis cov khoom siv kho kom zoo nkauj.

3, Kev lag luam kev loj hlob tiam sis thiab kev cov nyom

Kev txawj ntse thiab automation:

Dub Lub Hoobkas ": Automated ntau lawm kab, neeg hlau thauj khoom thiab unloading thiab vuam, AGV logistics, ua tiav 24-teev uninterrupted ntau lawm.

Kev sib koom ua ke ntawm software: Los ntawm CAD / CAM rau MES / ERP systems, ua tiav cov txheej txheem kev tswj hwm digital, txhim kho cov sijhawm teem sijhawm thiab kev muaj peev xwm taug qab.

Technology integration thiab innovation:

Composite processing: Laser txiav thiab stamping cov cav tov sib xyaw, ua ke nrog cov chaw khoov thiab cov neeg hlau, txo cov txheej txheem hloov dua siab tshiab thiab txhim kho qhov tseeb thiab ua haujlwm zoo.

Kev sib xyaw ua ke ntawm kev tsim khoom siv ntxiv (3D luam ntawv): Rau cov khoom siv ntau heev lossis cov khoom me me, 3D luam ntawv yog siv los tsim pwm lossis ncaj qha rau lawv, thiab tom qab ntawd ua ke nrog cov ntawv hlau.

Green manufacturing:

Siv cov txheej txheem zoo ib puag ncig (dej- cov xim pleev xim, cov hmoov zoo), ua kom zoo dua qub software kom txo cov khoom pov tseg, thiab rov ua dua cov khoom pov tseg thiab txiav cov kua dej.

Kev lag luam cov nyom:

Tus nqi siab: kev hloov pauv ntawm tus nqi raw khoom thiab nce nqi zog.

Cov txuj ci tsis txaus: Cov kws tshaj lij benders, welders, thiab cov txheej txheem engineers tsis tshua muaj.

Fragmentation ntawm kev txiav txim: Cov khoom me me, ntau yam, thiab kev xa khoom sai tau dhau los ua tus qauv, muab cov kev xav tau ntau dua ntawm kev tsim khoom yooj yim.
